Test Functions
QL-30/60 User Guide 105
The printout can be canceled with the following icon:
Figure 34: Font list
Device List
The Device list function prints out the most important information on hardware components of
the printer and connected devices. The printout occurs using the heat level and print speed
specified in the Setup > Printing menu.
Note: The printout occurs without taking the label gaps into consideration. This is why
continuous media is most suitable for this purpose.
1) Insert printable medium (labels, continuous media) which extends across the entire printing
width.
2) If the printout is to occur using thermal transfer printing, insert transfer ribbon with the
maximum width.
Table 38: Parameters of the Font list
Name Description
No. ID number of the font required for programming (command T).
Name Name with which the font is saved internally.
Type Type of font generation. It provides information on the variability of
the font and is important when programming (command T).
Description Explanations of the font: size, font family. The printout occurs in the
appropriate font.
Font list
Thu Aug 11 09:44:06 2016
QL-30
Firmware V5.00 (Jul 28, 2016) - #164162031171
No. Name Type Description
-1 _DEF1 Bitmap Default Font 12x12 dots
-2 _DEF2 Bitmap Default Font 16x16 dots
-3 _DEF3 Bitmap Default Font 16x32 dots
-4 OCR_A_I Bitmap OCR-A Size I
-5 OCR_B Bitmap OCR-B
3 BX000003 TrueType Swiss 721
5 BX000005 TrueType Swiss 721 Bold
596 BX000596 TrueType Monospace 821
1000 GHEI21M TrueType AR Heiti Medium GB-Mono
1010 GARUDA TrueType Garuda
To Next Page
