Configuration
QL-30/60 User Guide 87
Interfaces
• Start menu.
• Select Setup > Interfaces.
Support delay off Setting the switch-off delay (max. 2.5 s)
for the supporting air between the end of
label forwarding and switching on the
supporting air. The delay can be useful
to separate the rear edge of the label
from the carrier to avoid errors and to
improve the accuracy of label
positioning
0 ms
Start delay Delay (max. 2.5 s) between start signal
and the start of an labeling cycle.
For example, allows the use of product
sensors at conveyors.
0 ms
Vacuum delay On - The vacuum will be switched on
after the label feed is completed.
Off - The vacuum will be switched on
when the label feed starts.
Off
Vacuum control Setting the label transfer check from
printer to pad and from pad to product
by the vacuum sensor
On
Peel-off position Shift the position of the dispensed label
relative to the dispensing edge.
The setting can also be adjusted by the
software.
The settings of configuration and
software are added together.
0.0 mm
Table 26: Parameters of the Setup > Labeling menu (Continued)
Icon Parameter Meaning Default
