Diagnostic Functions
QL-30/60 User Guide 115
4) Select Diagnostics > Event log.
Figure 41: Event log
Save Data Stream
Note: Access only with external storage device!
The function Save data stream allows you to store data incoming via an interface as a .lbl file
to an external storage device (SD card, USB memory module) installed on the printer.
1) Insert SD card or USB memory module.
2) Start menu.
3) Select Diagnostics > Save data stream.
4) Select the external storage device.
5) Enter a file name.
The predefined name is composed of the identifier “log”, date, clock time and the suffix
“.lbl”, but may also be altered.
Confirm the selection.
6) In the status line of the display the data saving is indicated by the symbol.
7) Send print jobs. All data received by the printer are stored in the .lbl file.
