Test Functions
108 QL-30/60 User Guide
The printout can be canceled with the following icon:
Figure 36: Test grid
WiFi Status
Note: Access only when WLAN is activated!
The WiFi status function prints out a list with the most important parameters of the accessible
Wireless Access Points. The printout occurs using the heat level and print speed specified in
the Setup > Printing menu.
Note: The printout occurs without taking the label gaps into consideration. This is why
continuous media is most suitable for this purpose.
1) Insert printable medium (labels, continuous media) which extends across the entire printing
width.
2) If the printout is to occur using thermal transfer printing, insert transfer ribbon with the
maximum width.
3) Start menu.
4) Select Test > WiFi status.
