Printing Operation
50 QL-30/60 User Guide
Peel-off Mode
In Peel-off mode, the labels are automatically peeled off the liner after printing and presented
for removal. The liner is wound up by the internal rewinder. This mode is available only on the
peel-off printer versions. The printer must be equipped with a dispense plate.
Note: Peel-off mode must be activated in the software.
• In the most simple case the peel-off mode can be controlled without optional device by the
touchscreen display:
Start a print job in peel-off mode.
Start every peel-off cycle by pressing on the touchscreen display.
• When using the optional PS800 or PS900 the label in the peel position will be detected by
an optical sensor. After the label has been removed the next label will be printed and fed
to the peel position.
• With the applicators S1000 and S3200 or the dispense module S5104 the labels can be
applied to a product directly after printing.
Internal Rewinding
The labels are wound up internally after printing with the carrier medium for later use. This mode
is available only on the peel-off printer versions.
The label printer must be equipped with a rewind guide plate for this. See “Removing and
Installing the Rewind Guide Plate, Dispense Plate or Tear-off Plate” on page 46.
