Diagnostic Functions
QL-30/60 User Guide 117
6) Confirm the selection. The .png file will be stored in the root of the storage device.
Figure 43: Saved print image
Save System Log
Note: Access only with external storage device!
The function Save system log allows you to store several system files packed to a .zip file to an
external storage device (SD card, USB memory module) installed on the printer.
1) Insert SD card or USB memory module.
2) Start menu.
3) Select Diagnostics > Save system log.
4) Select the external storage device.
5) Enter a file name.
The predefined name is composed of the identifier “sys”, date, clock time and the suffix
“.png”, but may also be altered.
