Installation
22 QL-30/60 User Guide
Unpacking and Setting-up the Printer
1 Lift the label printer out of the box.
2 Check label printer for damage which may have occurred during transport.
3 Set up the printer on a level surface.
4 Remove foam transportation safeguards near the printhead.
5 Check delivery for completeness.
• Label printer
• Power cable
• USB cable
• WLAN stick
• Installation software
• Documentation
Installing the WLAN stick
Figure 4: Installing the WLAN stick
1 Remove the cover (1) with the Allen key (2).
2 Connect the WLAN stick (4) to the USB interface (3) in the control panel.
1
2
