Test Functions
QL-30/60 User Guide 107
Test Grid
The Test grid function prints out a geometric pattern on a background grid. This allows you to
assess the evenness of the print quality.
The printout occurs using the heat level and print speed specified in the Setup > Printing menu.
Note: The printout occurs without taking the label gaps into consideration. This is why
continuous media is most suitable for this purpose.
1) Insert printable medium (labels, continuous media) which extends across the entire printing
width.
2) If the printout is to occur using thermal transfer printing, insert transfer ribbon with the
maximum width.
3) Start menu.
4) Select Test > Test grid.
The geometric pattern is printed every 3 seconds once the Test grid function is started.
USB [a] Speed Type and revision of installed USB devices
• a: number of USB device
• Speed: data transfer speed (low, full, high)
The following properties are only displayed when the service key is
inserted:
• Mfr.: Manufacturer ID. This identifies the manufacturer of the USB
device
• Class: Code for the USB device class
• Protocol: Code for the type of communication with the USB device
• Phase: Internal value for troubleshooting
HEALTH Printhead voltage, charge state of the lithium battery on the PCB
CPU, temperature of CPU and printhead
Line pattern Lines differing in thickness at various distances. They are used to
evaluate the print quality.
Table 39: Parameters of the Device list (Continued)
Name Description
