Configuration
QL-30/60 User Guide 85
Peeling-off
Note: If peel-off module is not installed, access only with service key inserted.
• Start menu.
• Select Setup > Peeling-off.
Labeling
Note: If applicator is not installed, access only with service key inserted.
• Start menu.
• Select Setup > Labeling.
Table 25: Parameters of the Setup > Peeling-off menu
Icon Parameter Meaning Default
Peel-off position Shift the position of the dispensed label
relative to the dispensing edge.
The setting can also be adjusted by the
software.
The settings of configuration and
software are added together.
0.0 mm
Backfeed delay Delay time between removing the label
from the peel position and the backfeed
of the label.
250 ms
Backfeed position Offset of the backfeed movement 1.0 mm
Table 26: Parameters of the Setup > Labeling menu
Icon Parameter Meaning Default
Transfer mode Setting the operation mode Stamp on,
Roll on, Blow on
Stamp on
