Configuration
86 QL-30/60 User Guide
Cycle sequence Setting the application mode
Print-Apply/Apply-Print
• Print-Apply: An external start signal
releases the print of a label and
following the application of the label.
After a cycle is complete, the pad
without label waits in the start
position.
• Apply-Print: An extra signal starts the
print of the first label and the transfer
of the label to the pad. The external
start signal releases the application of
the label and following the print and
transfer of the next label. After a cycle
is complete, the pad with a label is in
the waiting position.
Print-Apply
Waiting position
• Up: Pad waits in the start position for
the start signal
• Down: Pad waits in the labeling
position for the start signal
Only at Transfer mode = Blow on and
Cycle sequence = Apply-Print
up
Blow time Switch-on time (max. 2.5 s) of the
blowing air for the label transfer
Only at Transfer mode = Blow on
1000 ms
Roll-on time Dwell time (max. 5 s) of the pad in the
labeling position
Only at Transfer mode = Roll on
1000 ms
Support delay on Setting the switch-on delay (max. 2.5 s)
for the supporting air between print start
and switching on the supporting air. The
delay prevents swirling at the front of the
label and, consequently, avoids faults
when the label is being picked up from
the printer.
0 ms
Table 26: Parameters of the Setup > Labeling menu (Continued)
Icon Parameter Meaning Default
