QuickLabel QL-60 User Manual

Test Functions
106 QL-30/60 User Guide
3) Start menu.
4) Select Test > Device list.
The printout can be canceled with the following icon:
Figure 35: Device list
Parameters marked italic are only printed when the service key is inserted
Table 39: Parameters of the Device list
Name Description
CPU Type and serial number of the PCB CPU
Revision of PCB CPU and FPGA
TPH Print width and resolution of the installed thermal printhead
IF [x] Type of interfaces installed
x: Number of interface
IFFS Size of the Internal Flash File System
USBMEM Size and type of an installed USB storage device
SD Size and type of an installed SD card

QuickLabel QL-60 Specifications

General

Brand	QuickLabel
Model	QL-60
Category	Label Maker
Language	English
