Alteon Application Switch Operating System Application Guide
Spanning Tree Protocol
Document ID: RDWR-ALOS-V2900_AG1302 109
3. Set the mode to Multiple Spanning Tree, and configure MSTP region parameters.
4. Assign VLANs to STGs.
5. Turn off Layer 3 forwarding.
>> Main# /cfg/l2/mrst
(Select Multiple Spanning Tree menu)
>> Multiple Spanning Tree# mode mstp
(Set mode to Multiple Spanning Trees)
>> Multiple Spanning Tree# on
(Turn Multiple Spanning Trees on)
>> Multiple Spanning Tree# name xxxxxx
(Define the region name)
>> Main# /cfg/l2/stg 2
>> Spanning Tree Group 2# add 2
>> Main# /cfg/l3/frwd off
>> IP Forwarding# apply
>> IP Forwarding# save
