Radware Alteon User Manual

Alteon Application Switch Operating System Application Guide
Open Shortest Path First (OSPF)
154 Document ID: RDWR-ALOS-V2900_AG1302
5. Define the transit area. The area that contains the virtual link must be configured as a transit
area.
6. Attach the network interface to the backbone.
7. Attach the network interface to the transit area.
8. Configure the virtual link. The nbr router ID configured in this step must be the same as the
router ID that is configured for step 2
in the procedure for Alteon 2.
9. Apply and save the configuration changes.
Configuring OSPF for a Virtual Link on Alteon 2
1. Configure IP interfaces on each network that is attached to OSPF areas.
Two IP interfaces are needed on Alteon 2: the transit area network on 10.10.12.0/24, and the
stub area network on 10.10.24.0/24.
>> OSPF Area (index) 0 # /cfg/l3/ospf/aindex 1
(Select menu for area index 1)
>> OSPF Area (index) 1 # areaid 0.0.0.1
(Set the area ID for OSPF area 1)
>> OSPF Area (index) 1 # type transit
(Define area as transit type)
>> OSPF Area (index) 1 # enable
(Enable the area)
>> OSPF Area (index) 1 # /cfg/l3/ospf/if 1
(Select OSPF menu for IP interface 1)
>> OSPF Interface 1 # aindex 0
(Attach network to backbone index)
>> OSPF Interface 1 # enable
(Enable the backbone interface)
>> OSPF Interface 1 # /cfg/l3/ospf/if 2
(Select OSPF menu for IP interface 2)
>> OSPF Interface 2 # aindex 1
(Attach network to transit area index)
>> OSPF Interface 2 # enable
(Enable the transit area interface)
>> OSPF Interface 2 # /cfg/l3/ospf/virt 1
(Specify a virtual link number)
>> OSPF Virtual Link 1 # aindex 1
(Specify the transit area for the virtual
link)
>> OSPF Virtual Link 1 # nbr 10.10.14.1
(Specify the router ID of the recipient)
>> OSPF Virtual Link 1 # enable
(Enable the virtual link)
>> OSPF Interface 2 # apply 1
(Global command to apply all changes)
>> OSPF Interface 2 # save
(Global command to save all changes)
>> # /cfg/l3/if 1
(Select menu for IP interface 1)
>> IP Interface 1 # addr 10.10.12.2
(Set IP address on transit area net-
work)
>> IP Interface 1 # mask 255.255.255.0
(Set IP mask on transit area network)
>> IP Interface 1 # enable
(Enable IP interface 1)
>> IP Interface 1 # /cfg/l3/if 2
(Select menu for IP interface 2)
>> IP Interface 2 # 10.10.24.1
(Set IP address on stub area network)
