Alteon Application Switch Operating System Application Guide

ADC-VX Management

Document ID: RDWR-ALOS-V2900_AG1302 417

Settings Menu

The Settings menu is used to configure the following dashboard settings:

• Sampling interval

• Default chart type

• vADC chart selection

To configure the dashboard settings

1. Expand the Dashboard option to display the Settings menu.

The following panel displays:

Service Utilization Chart

(continued)

Line The tool tip displays detailed data per vADC.

The following is a sample resource throughput line chart:

Table 36: Chart Views (cont.)

Chart View Chart Type Behavior
