Alteon Application Switch Operating System Application Guide
High Availability
Document ID: RDWR-ALOS-V2900_AG1302 561
Active-Active Configuration
Figure 84 - Active-Active Configuration Example, page 561 illustrates an active-active configuration
between two Alteons. The following are considerations for a IPv6 active-active configuration:
1. Layer 2 (port and VLAN) configuration:
— Each VLAN must be configured per interface.
2. Layer 3 interface and VRRP configuration:
— In this example, tracking is performed by Layer 4 ports so that the two virtual routers fail
over when one of the master virtual routers declare itself as the backup.
Figure 84: Active-Active Configuration Example
