Alteon Application Switch Operating System Application Guide
ADC-VX Management
Document ID: RDWR-ALOS-V2900_AG1302 413
Dashboard Charts
The dashboard displays two charts:
• Resource utilization (CPU and memory)—This chart consists of two metrics: CPU and
memory consumption per vADC.
• Service usage of the set limit (in percents)—This chart displays throughput, SSL, and
compression consumption per vADC.
You can choose one of two chart types to display for each dashboard:
• Bar chart
• Line chart
Chart Filters
You can select one of the following filters based on operating capacity:
• Customize, default view
• vADCs operating at 90% capacity
• vADCs operating at 80% capacity
• vADCs operating at 70% capacity
• Time (real-time, 1 hour, 24 hours)
Tool Tips
All charts include tool tips which provide more detailed information for a given vADC.
For example, the tool tip for the Throughput Utilization chart may state “Throughput utilization is
500Mb/1Gb”, meaning that the vADC is using on average 500 Mb out of the allocated 1 Gb.
Chart Behavior
Table 36 describes the behavior of each chart according to the selected chart type:
