ADC-VX Management

414 Document ID: RDWR-ALOS-V2900_AG1302

Table 36: Chart Views

Chart View Chart Type Behavior

Resource Utilization

Chart

Bar When using filters:

• The real-time filter displays real time data.

• The hour displays the maximum value of the last

hour.

• The day filter displays the maximum value within

the last 24 hours.

The following is a sample resource utilization bar chart:
