Alteon Application Switch Operating System Application Guide

ADC-VX Management

Document ID: RDWR-ALOS-V2900_AG1302 415

Line This displays the CPU utilization. Multiple lines in

different colors are used to represent the different

vADCs.

The following is a sample resource utilization line chart:
