Alteon Application Switch Operating System Application Guide
Open Shortest Path First (OSPF)
160 Document ID: RDWR-ALOS-V2900_AG1302
3. Configure client and server processing on specific ports.
4. Enable direct access mode.
5. Configure the primary virtual server. Alteon 1 is preferred for virtual server 10.10.10.1.
6. Configure the backup virtual server. Alteon 1 acts as a backup for virtual server 10.10.10.2.
Both virtual servers in this example are configured with the same real server group and provide
identical services.
7. Enable OSPF on Alteon 1.
>> # /cfg/slb/real 1
(Select menu for real server 1)
>> Real server 1 # rip 100.100.100.25
(Set the IP address for real server 1)
>> Real server 1 # ena
(Enable the real server)
>> Real server 1 # /cfg/slb/real 2
(Select menu for real server 2)
>> Real server 2 # rip 100.100.100.26
(Set the IP address for real server 2)
>> Real server 2 # ena
(Enable the real server)
>> Real server 2 # /cfg/slb/group 1
(Select menu for real server group 1)
>> Real server group 1 # add 1
(Add real server 1 to group)
>> Real server group 1 # add 2
(Add real server 2 to group)
>> Real server group 1 # enable
(Enable the group)
>> Real server group 1 # /cfg/slb/on
(Turn SLB on)
>> Layer 4 # /cfg/slb/port 4
(Select port 4)
>> SLB Port 4 # client ena
(Enable client processing on port 4)
>> SLB Port 4 # /cfg/slb/port 5
(Select port 5)
>> SLB Port 5 # server ena
(Enable server processing on port 5)
>> Layer 4 Port 5 # /cfg/slb/adv
(Select the SLB advance menu)
>> Layer 4 Advanced # direct ena
(Enable DAM)
>> Layer 4 Advanced# ...
(Return to the SLB menu)
>> Layer 4 # /cfg/slb/virt
(Select menu for virtual server 1)
>> Virtual server 1 # vip 10.10.10.1
(Set the IP address for virtual server 1)
>> Virtual server 1 # ena
(Enable the virtual server)
>> Virtual server 1 # service http
(Select menu for service on virtual server)
>> Virtual server 1 http service # group 1
(Use real server group 1 for HTTP service)
>> Virtual server 2 http service # /cfg/
slb/virt 2
(Select menu for virtual server 2)
>> Virtual server 1 # vip 10.10.10.2
(Set the IP address for virtual server 2)
>> Virtual server 1 # ena
(Enable the virtual server)
>> Virtual server 1 # service http
(Select menu for service on virtual server)
>> Virtual server 1 http service # group 1
(Use real server group 1 for HTTP service)
