Alteon Application Switch Operating System Application Guide
Open Shortest Path First (OSPF)
Document ID: RDWR-ALOS-V2900_AG1302 163
3. Configure IP interfaces for each network that will be attached to OSPF areas.
4. Enable OSPF on Alteon 2.
5. Define the backbone.
6. Define the stub area.
7. Attach the network interface to the backbone.
8. Attach the network interface to the stub area.
>> Virtual server 1 # service http
(Select menu for service on virtual
server)
>> Virtual server 1 http service # group 1
(Use real server group 1 for http
service)
>> Virtual server 2 http service # /cfg/slb/
virt 2
(Select menu for virtual server 2)
>> Virtual server 1 # vip 10.10.10.2
(Set the IP address for virtual server 2)
>> Virtual server 1 # enable
(Enable the virtual server)
>> Virtual server 1 # service http
(Select menu for service on virtual
server)
>> Virtual server 1 # group
(Use real server group 1 for http
service)
>> Virtual server 1# /cfg/l3/if 1
(Select menu for IP Interface 1)
>> IP Interface 1 # addr 10.10.10.6
(Set IP address on backbone network)
>> IP Interface 1 # enable
(Enable IP interface 1)
>> IP Interface 1 # /cfg/l3/if 2
(Select menu for IP Interface 2)
>> IP Interface 2 # addr 100.100.100.41
(Set IP address on stub area network)
>> IP Interface 2 # enable
(Enable IP interface 2)
>> IP Interface 2 # /cfg/l3/ospf/on
(Enable OSPF on Alteon 2)
>> Open Shortest Path# addr 10.10.10.6
(Select menu for area index 0)
>> OSPF Area (index) 0 # areaid 0.0.0.0
(Set the ID for backbone area 0)
>> OSPF Area (index) 0 # type transit
(Define backbone as transit type)
>> OSPF Area (index) 0 # enable
(Enable the area)
>> OSPF Area (index) 0 # /cfg/l3/ospf/aindex 1
(Select menu for area index 1)
>> OSPF Area (index) 1 # areaid 0.0.0.1
(Set the ID for stub area 1)
>> OSPF Area (index) 1 # type stub
(Define area as stub type)
>> OSPF Area (index) 1 # enable
(Enable the area)
>> OSPF Area (index) 1 # /cfg/l3/ospf/if 1
(Select OSPF menu for IP interface 1)
>> OSPF Interface 1 # aindex 0
(Attach network to backbone index)
>> OSPF Interface 1 # enable
(Enable the backbone interface)
