Alteon Application Switch Operating System Application Guide

Server Load Balancing

204 Document ID: RDWR-ALOS-V2900_AG1302

Figure 35: Mapped and Non-Mapped Server Access

Using delayed binding, Alteon intercepts the client SYN request before it reaches the server. Alteon

responds to the client with a SYN ACK that contains embedded client information. Alteon does not

allocate a session until a valid SYN ACK is received from the client or the three-way handshake is

complete.
