Alteon Application Switch Operating System Application Guide
Filtering and Traffic Manipulation
398 Document ID: RDWR-ALOS-V2900_AG1302
The following example creates two IPv6 filters for Port 1. Filter 1 allows the exchange Neighbors
Solicitation packets, and Filter 2 allows the movement of bridged HTTP traffic.
Example IPv6 Filtering Example
1. Globally enable Layer 4 load balancing. Layer 4 load balancing must be enabled to allow filter
processing to take place.
2. Create Filter 1 to allow the passage of Neighbors Solicitation packets.
3. Create Filter 2 to allow the movement of bridged HTTP traffic.
s
/cfg/slb/filt <filter Number> /adv/
8021p
All 802.1p menu commands.
/cfg/slb/filt <filter Number> /adv/
proxyadv
All Proxy menu commands.
/cfg/slb/filt <filter Number> /adv/
redir
All Redirection menu commands.
/cfg/slb/filt <filter Number> /adv/
security/ratelim
All Rate Limiting menu commands.
>> Main# /cfg/slb/on
>> Main# /cfg/slb/filt 1/ena
(Enable Filter 1)
>> Filter 1# action allow
(Specify an ALLOW filter)
>> Filter 1# ipver v6
(Specify an IPv6 filter)
>> Filter 1# sip 2001:0:0:0:0:0:0:0
(Specify source IP)
>> Filter 1# smask 64
(Specify IPv6 source prefix)
>> Filter 1# dip ff00:0:0:0:0:0:0:0
(Specify destination IP)
>> Filter 1# dmask 8
(Specify IPv6 destination prefix)
>> Filter 1# vlan any
(Specify VLAN settings)
>> Main# /cfg/slb/filt 2/ena
(Enable Filter 2)
>> Filter 2# action allow
(Specify an ALLOW filter)
>> Filter 2# ipver v6
(Specify an IPv6 filter)
>> Filter 2# sip 2001:0:0:0:0:0:0:1
(Specify source IP)
>> Filter 2# smask 128
(Specify IPv6 source prefix)
>> Filter 2# dip 2001:0:0:0:0:0:0:8
(Specify destination IP)
>> Filter 2# dmask 128
(Specify IPv6 destination prefix)
>> Filter 2# proto tcp
(Specify filter protocol)
>> Filter 2# sport any
(Specify source port)
Table 34: IPv6 Filter Configuration Commands
Command Menu Supported Commands
