Alteon Application Switch Operating System Application Guide
ADC-VX Management
Document ID: RDWR-ALOS-V2900_AG1302 437
Default Image
The default image is the ADC image used in the following scenarios:
• When switching from standalone to ADC-VX
• When creating a new vADC in ADC-VX mode
To assign a default image in ADC-VX
1. Access the Active Switch Configuration Boot menu.
ADC-VX
Infrastructure Update
AlteonOS-<version>-
<platform>-VX.img
For example:
AlteonOS-29.0.0.0-
5000-VX.img
This image is an upgrade image for the ADC-VX
infrastructure. It is only issued when an update is
available to the ADC-VX infrastructure.
Note: This image can only be installed when an
image is first installed and set as the default
image.
USB Recovery System
Recovery-AlteonOS-
<version>-
<platform>.zip
For example:
Recovery-AlteonOS-
29.0.0.0-4416.zip
This image is a USB recovery image for the system
image.
It is used for the entire system, not for only one
element (standalone mode, vADC mode, or ADC-VX
infrastructure
).
>> ADC-VX - Main# boot
[Boot Options Menu]
single - Switch between ADC-VX and Standalone
vadc - Restart selected vADC process
image - Select software image to use on next boot
dimage - Select default image
conf - Select config block to use on next boot
gtimg - Download new software image via FTP/TFTP/SCP
reset - Reset switch
cur - Display current boot options
Table 37: Image Formats
Image Format File Name Description
