Alteon Application Switch Operating System Application Guide

High Availability

526 Document ID: RDWR-ALOS-V2900_AG1302

To configure Layer 3 virtual router settings for services

1. On the active Alteon, configure each service.

For example, for an HTTP service:

2. On the active Alteon, configure a different virtual router for each service.

3. On the standby Alteon, copy these active Alteon settings, but lower the priority of each virtual

router.

>> Main # /cfg/slb/virt 1

(Select the virtual server)

>> Main # /cfg/slb/virt 1/ena

(Enable the virtual server)

>> Main # /cfg/slb/virt 1/vip 10.10.10.200

(Set the virtual server virtual IP)

>> Main # /cfg/slb/virt 1/service 80 http

(Specify the service)

>> Main # /cfg/l3/vrrp/on

(Enable VRRP)

>> Main # /cfg/l3/vrrp/vr 4

(Specify the virtual router number for

the service)

>> Main # /cfg/l3/vrrp/vr 4/ena

(Enable the virtual router)

>> Main # /cfg/l3/vrrp/vr 4/vrid 55

(Set the virtual router ID)

>> Main # /cfg/l3/vrrp/vr 4/if 1

(Select a device IP interface)

>> Main # /cfg/l3/vrrp/vr 4/prio 101

(Set the priority bias for the virtual

router)

>> Main # /cfg/l3/vrrp/vr 4/addr 10.10.10.200

(Set the virtual server IP address)
