Alteon Application Switch Operating System Application Guide

High Availability

564 Document ID: RDWR-ALOS-V2900_AG1302

— IPv6 VIP 1 HTTP service configuration:

— Layer 4 ports configuration:

— Synchronization configuration:

/cfg/slb/virt 1

ena

ipver v6

vip 3000:3:3:0:0:0:0:ffff

vname "v6http"

/cfg/slb/virt 1/service http

group 1

/cfg/slb/port 1

client ena

hotstan en

/cfg/slb/port 2

server ena

hotstan en

/cfg/slb/port 3

intersw ena

vlan 400

/cfg/slb/port 4

intersw ena

vlan 400

/cfg/slb/sync

prios d

/cfg/slb/sync/peer 1

ena

addr 192.168.0.2
