Alteon Application Switch Operating System Application Guide
Bandwidth Management
Document ID: RDWR-ALOS-V2900_AG1302 785
3. Configure BWM contracts and apply the appropriate policies to the contracts. In this example,
the policy numbers correspond to the contract numbers.
4. Identify the defined string IDs that were configured.
For easy configuration and identification, each defined string is assigned an ID number, as
shown in the following table. The third column shows the BWM contracts to assign to the strings
in this example.
5. Assign BWM contracts to each string using the syntax shown.
6. Verify that the strings and contracts are assigned properly.
7. Configure a real server to handle the URL request.
>> Main# /cfg/bwm/pol 1/hard 3M/soft 2M/res 1M
>> Policy 1# /cfg/bwm/pol 2/hard 4M/soft 3M/res 2M
>> Policy 2# /cfg/bwm/pol 3/hard 1M/soft 500k/res 250k
>> Policy 3# /cfg/bwm/pol 4/hard 2M/soft 1M/res 500k
>> Main# /cfg/bwm/cont 1/policy 1
>> BW Contract 1# /cfg/bwm/cont 2/policy 2
>> BW Contract 2# /cfg/bwm/cont 3/policy 3
>> BW Contract 3# /cfg/bwm/cont 4/policy 4
(Apply Policy 1 to Contract 1)
>> # /cfg/slb/layer7/slb/cur
ID SLB String BWM Contract
1any 4
2.gif 1
3.jpg 1
4.cgi 2
5.bin 2
6.exe 2
7.html 3
>> Main# /cfg/slb/layer7/slb/cont <String ID> < BWM Contract number>
>> Server Load Balance Resource# cur
Number of entries: 2
1: any, cont 4
2: .gif, cont 1
3: .jpg, cont 1
4: .cgi, cont 2
5: .bin, cont 2
6: .exe, cont 2
7: .html, cont 3
>> # /cfg/slb/real 2/layer7/addlb <SLB string ID>
