2. Configure Filter 9 and Filter 10.

3. Apply and save the configuration.

Example IPv6 Redirection Filter

Figure 138 - TCP Service Port Based HTTP Redirection, page 832 illustrates an IPv6 redirection

filter:

/c/slb/filt 9

ena

action redir

ipver v4

proto tcp

dport http

/c/slb/filt 9/adv/layer7

l7lkup ena

addrd 3>4

/c/slb/filt 10

ena

action redir

ipver v4

dip 205.10.10.10

proto tcp

dport http

/c/slb/filt 10/adv/layer7

l7lkup ena

addrd 2>4
