Section 2 CPU

Rev. 7.00 Mar 10, 2005 page 65 of 652

REJ09B0042-0700

H'0000

H'0029

H'002A

H'1FFF

H'F740

H'F74F

H'FD80

H'FF7F

H'FF80

H'FFFF

Interrupt vector area

On-chip ROM

8 Kbytes

(8192 bytes)

512 bytesOn-chip RAM

Internal I/O registers

(128 bytes)

Not used

LCD RAM

(16 bytes)

Figure 2.16(5) H8/38020, H8/38020S, and H8/38120 Memory Map
