Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 300 of 652
REJ09B0042-0700
9.6 Watchdog Timer
9.6.1 Overview
The watchdog timer has an 8-bit counter that is incremented by an input clock. If a system
runaway allows the counter value to overflow before being rewritten, the watchdog timer can reset
the chip internally. Note that stabilization times for the H8/38024, H8/38024S, and H8/38024R
Group and for the H8/38124 Group are different.
Features
Features of the watchdog timer are given below.
• Incremented by internal clock source (φ/8192 or φw/32) on the H8/38024, H8/38024S, and
H8/38024R Group.
• On the H8/38124 Group, 10 internal clocks (φ/64, φ/128, φ/256, φ/512, φ/1024, φ/2048,
φ/4096, φ/8192, φw/32, or watchdog on-chip oscillator) are available for selection for use by
the counter.
• A reset signal is generated when the counter overflows. The overflow period can be set from 1
to 256 times the selected clock (from approximately 4 ms to 1,000 ms when φ = 2.00 MHz).
• Use of module standby mode enables this module to be placed in standby mode independently
when not used. See section 5.9, Module Standby Mode, for details.
