Section 5 Power-Down Modes
Rev. 7.00 Mar 10, 2005 page 133 of 652
REJ09B0042-0700
5.4.2 Clearing Watch Mode
Watch mode is cleared by an interrupt (timer A, timer F, timer G, IRQ0, or WKP7 to WKP0) or
by input at the
RES
pin.
• Clearing by interrupt
When watch mode is cleared by interrupt, the mode to which a transition is made depends on
the settings of LSON in SYSCR1 and MSON in SYSCR2. If both LSON and MSON are
cleared to 0, transition is to active (high-speed) mode; if LSON = 0 and MSON = 1, transition
is to active (medium-speed) mode; if LSON = 1, transition is to subactive mode. When the
transition is to active mode, after the time set in SYSCR1 bits STS2 to STS0 has elapsed, a
stable clock signal is supplied to the entire chip, watch mode is cleared, and interrupt exception
handling starts. Watch mode is not cleared if the I bit of CCR is set to 1 or the particular
interrupt is disabled in the interrupt enable register.
• Clearing by
RES
input
Clearing by
RES
pin is the same as for standby mode; see 2. Clearing by
RES
pin in section
5.3.2, Clearing Standby Mode.
5.4.3 Oscillator StabilizationTime after Watch Mode is Cleared
The wait time is the same as for standby mode; see section 5.3.3, Oscillator Stabilization Time
after Standby Mode is Cleared.
5.4.4 Notes on External Input Signal Changes before/after Watch Mode
See section 5.3.5, Notes on External Input Signal Changes before/after Standby Mode.
