Renesas H8 Series Hardware Manual

Section 11 10-Bit PWM
Rev. 7.00 Mar 10, 2005 page 395 of 652
REJ09B0042-0700
11.2.3 Clock Stop Register 2 (CKSTPR2)
LVDCKSTP
*
WDCKSTP
PW1CKSTP LDCKSTP—— PW2CKSTP AECKSTP
76543210
1
1111111
R/W
R/W R/W R/W
——R/W
R/W
Bit
Initial value
Read/Write
Note: * Bits 6 and 5 are also reserved on products other than the H8/38124 Group.
CKSTPR2 is an 8-bit read/write register that performs module standby mode control for peripheral
modules. Only the bit relating to the PWM is described here. For details of the other bits, see the
sections on the relevant modules.
Bits 4 and 1—PWM Module Standby Mode Control (PWmCKSTP)
Bits 4 and 1 control setting and clearing of module standby mode for the PWMm.
PWmCKSTP Description
0 PWMm is set to module standby mode
1 PWMm module standby mode is cleared (initial value)
