3. AI
STOP2
is the current at reset and in standby, watch, subactive, and subsleep modes
while the A/D converter is idle.
4. Conversion time: 62 µs.
16.6.5 LCD Characteristics
Table 16.19 shows the LCD characteristics.
Table 16.19 LCD Characteristics
V
CC
= 1.8 V to 3.6 V, AV
CC
= 1.8 V to 3.6 V, V
SS
= AV
SS
= 0.0 V
Values
Item Symbol
A
pp
licable
Pins Min Typ Max Unit
Test
Conditions
Reference
Figure
Segment driver
drop voltage
V
DS
SEG
1
to
SEG
32
——0.6V I
D
= 2 µA
V
1
= 2.7 V to 3.6 V
*
1
Common driver
drop voltage
V
DC
COM
1
to
COM
4
——0.3V I
D
= 2 µA
V
1
= 2.7 V to 3.6 V
*
1
LCD power supply
split-resistance
R
LCD
1.5 3.0 7.0 MΩ Between V
1
and
V
SS
Liquid crystal
display voltage
V
LCD
V
1
2.2 — 3.6 V
*
2
Notes: 1. The voltage drop from power supply pins V
1
, V
2
, V
3
, and VSS to each segment pin or
common pin.
2. When the liquid crystal display voltage is supplied from an external power source,
ensure that the following relationship is maintained: V
CC
≥ V
1
≥ V
2
≥ V
3
≥ V
SS
.
