Section 6 ROM
Rev. 7.00 Mar 10, 2005 page 144 of 652
REJ09B0042-0700
6.2 H8/38024 PROM Mode
6.2.1 Setting to PROM Mode
If the on-chip ROM is PROM, setting the chip to PROM mode stops operation as a
microcontroller and allows the PROM to be programmed in the same way as the standard
HN27C101 EPROM. However, page programming is not supported. Table 6.1 shows how to set
the chip to PROM mode.
Table 6.1 Setting to PROM Mode
Pin Name Setting
TEST High level
PB
0
/AN
0
Low level
PB
1
/AN
1
PB
2
/AN
2
High level
6.2.2 Socket Adapter Pin Arrangement and Memory Map
A standard PROM programmer can be used to program the PROM. A socket adapter is required
for conversion to 32 pins.
Figure 6.2 shows the pin-to-pin wiring of the socket adapter. Figure 6.3 shows a memory map.
