Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 260 of 652
REJ09B0042-0700
9.3.4 Timer C Operation States
Table 9.6 summarizes the timer C operation states.
Table 9.6 Timer C Operation States
Operation Mode Reset Active Sleep Watch
Sub-
active
Sub-
sleep Standby
Module
Standby
TCC Interval Reset Functions Functions Halted
Functions/
Halted
*
Functions/
Halted
*
Halted Halted
Auto reload Reset Functions Functions Halted
Functions/
Halted
*
Functions/
Halted
*
Halted Halted
TMC Reset Functions Retained Retained Functions Retained Retained Retained
Note: * When φw/4 is selected as the TCC internal clock in active mode or sleep mode, since the
system clock and internal clock are mutually asynchronous, synchronization is maintained
by a synchronization circuit. This results in a maximum count cycle error of 1/φ (s). When
the counter is operated in subactive mode or subsleep mode, either select φw/4 as the
internal clock or select an external clock. The counter will not operate on any other
internal clock. If φw/4 is selected as the internal clock for the counter when φw/8 has been
selected as subclock φ
SUB
, the lower 2 bits of the counter operate on the same cycle, and
the operation of the least significant bit is unrelated to the operation of the counter.
