Section 6 ROM
Rev. 7.00 Mar 10, 2005 page 176 of 652
REJ09B0042-0700
6.10.2 Programmer Mode Commands
The following commands are supported in programmer mode.
• Memory Read Mode
• Auto-Program Mode
• Auto-Erase Mode
• Status Read Mode
Status polling is used for auto-programming, auto-erasing, and status read modes. In status read
mode, detailed internal information is output after the execution of auto-programming or auto-
erasing. Table 6.13 shows the sequence of each command. In auto-programming mode, 129 cycles
are required since 128 bytes are written at the same time. In memory read mode, the number of
cycles depends on the number of address write cycles (n).
Table 6.13 Command Sequence in Programmer Mode
1st Cycle 2nd Cycle
Command Name
Number
of Cycles
Mode Address Data Mode Address Data
Memory read 1 + n Write X H'00 Read RA Dout
Auto-program 129 Write X H'40 Write WA Din
Auto-erase 2 Write X H'20 Write X H'20
Status read 2 Write X H'71 Write X H'71
n: the number of address write cycles
