Renesas H8 Series Hardware Manual

Section 16 Electrical Characteristics
Rev. 7.00 Mar 10, 2005 page 453 of 652
REJ09B0042-0700
Section 16 Electrical Characteristics
16.1 H8/38024 Group ZTAT Version and Mask ROM Version Absolute
Maximum Ratings
Table 16.1 lists the absolute maximum ratings.
Table 16.1 Absolute Maximum Ratings
Item Symbol Value Unit Note
Power supply voltage V
CC
–0.3 to +7.0 V
*
Analog power supply voltage AV
CC
–0.3 to +7.0 V
Programming voltage V
PP
–0.3 to +13.0 V
Input voltage Ports other than Port B
and IRQAEC
V
in
–0.3 to V
CC
+0.3 V
Port B AV
in
–0.3 to AV
CC
+0.3 V
IRQAEC HV
in
–0.3 to +7.3 V
Port 9 pin voltage V
P9
–0.3 to +7.3 V
Operating temperature T
opr
–20 to +75
(regular
specifications)
°C
–40 to +85
(wide-range
specifications)
°C
Storage temperature T
stg
–55 to +125 °C
Note: * Permanent damage may occur to the chip if maximum ratings are exceeded. Normal
operation should be under the conditions specified in Electrical Characteristics. Exceeding
these values can result in incorrect operation and reduced reliability.
