Renesas H8 Series Hardware Manual

Section 14 Power-On Reset and Low-Voltage Detection Circuits (H8/38124 Group Only)
Rev. 7.00 Mar 10, 2005 page 442 of 652
REJ09B0042-0700
14.2.3 Low-Voltage Detection Counter (LVDCNT)
Bit 76543210
CNT7 CNT6 CNT5 CNT4 CNT3 CNT2 CNT1 CNT0
Initial value 0 0 0 0 0 0 0 0
Read/Write R R R R R R R R
LVDCNT is a read-only 8-bit up-counter. Counting begins when 1 is written to LVDE. The
counter increments using φ/4 as the clock source until it overflows by switching from H'FF to
H'00, at which time the OVF bit in the LVDSR register is set to 1, indicating that the on-chip
reference voltage generator has stabilized. If the LVD function is used, it is necessary to stand by
until the counter has overflowed. The initial value of LVDCNT is H'00.
14.2.4 Clock Stop Register 2 (CKSTPR2)
Bit 76543210
LVDCKSTP ——PW2CKSTP AECKSTP WDCKSTP PW1CKSTP LDCKSTP
Initial value 1 1 1 1 1 1 1 1
Read/Write R/W — — R/W R/W R/W R/W R/W
CKSTPR2 is an 8-bit read/write register. It is used to control the module’s module standby mode.
Only the bits relevant to the LVD function are described in this section. Refer to the sections on
the other modules for information about the other bits.
Bit 7—LVD Module Standby Control (LVDCKSTP)
This bit is used to control setting of the LVD function to module standby status and cancellation of
that status.
Bit 7
LVDCKSTP Description
0 Sets LVD to module standby status
1 Cancels LVD module standby status (initial value)
Note: This bit is implemented on the H8/38124 Group only. On other products it is always read as
1 and cannot be written to.
