Section 2 CPU
Rev. 7.00 Mar 10, 2005 page 40 of 652
REJ09B0042-0700
2.5.1 Data Transfer Instructions
Table 2.4 describes the data transfer instructions. Figure 2.5 shows their object code formats.
Table 2.4 Data Transfer Instructions
Instruction Size
*
Function
MOV B/W (EAs) → Rd, Rs → (EAd)
Moves data between two general registers or between a general
register and memory, or moves immediate data to a general
register.
The Rn, @Rn, @(d:16, Rn), @aa:16, #xx:16, @–Rn, and @Rn+
addressing modes are available for word data. The @aa:8
addressing mode is available for byte data only.
The @–R7 and @R7+ modes require word operands. Do not
specify byte size for these two modes.
POP W @SP+ → Rn
Pops a 16-bit general register from the stack. Equivalent to
MOV.W @SP+, Rn.
PUSH W Rn → @–SP
Pushes a 16-bit general register onto the stack. Equivalent to
MOV.W Rn, @–SP.
Notes: * Size: Operand size
B: Byte
W: Word
Certain precautions are required in data access. See section 2.9.1, Notes on Data Access, for
details.
Figure 2.7 lists the format of the bit manipulation instructions.
