Section 6 ROM
Rev. 7.00 Mar 10, 2005 page 156 of 652
REJ09B0042-0700
6.5.3 Block Configuration
Figure 6.8 shows the block configuration of the flash memory. The thick lines indicate erasing
units, the narrow lines indicate programming units, and the values are addresses. In versions with
32 Kbytes of flash memory, the flash memory is divided into 1 Kbyte × 4 blocks and 28 Kbytes ×
1 block. In versions with 16 Kbytes of flash memory, the flash memory is divided into 1 Kbyte × 4
blocks and 12 Kbytes × 1 block. Erasing is performed in these units. Programming is performed in
128-byte units starting from an address with lower eight bits H'00 or H'80.
H'007F
H'0000 H'0001 H'0002
H'00FF
H'0080 H'0081 H'0082
H'03FF
H'0380 H'0381 H'0382
H'047F
H'0400 H'0401 H'0402
H'04FF
H'0480 H'0481 H'0482
H'07FF
H'0780 H'0781 H'0782
H'087F
H'0800 H'0801 H'0802
H'08FF
H'0880 H'0881 H'0882
H'0BFF
H'0B80 H'0B81 H'0B82
H'0C7F
H'0C00 H'0C01 H'0C02
H'0CFF
H'0C80 H'0C81 H'0C82
H'0FFF
H'0F80 H'0F81 H'0F82
H'107F
H'1000 H'1001 H'1002
H'10FF
H'1080 H'1081 H'1082
H'7FFF
H'7F80 H'7F81 H'7F82
Programming unit: 128 bytes
Programming unit: 128 bytes
Programming unit: 128 bytes
Programming unit: 128 bytes
Programming unit: 128 bytes
1 Kbyte
Erase unit
1 Kbyte
Erase unit
1 Kbyte
Erase unit
1 Kbyte
Erase unit
28 Kbytes
Erase unit
Figure 6.8(1) Block Configuration of 32-Kbyte Flash Memory
