Section 6 ROM

Rev. 7.00 Mar 10, 2005 page 157 of 652

REJ09B0042-0700

H'007F

H'0000 H'0001 H'0002

H'00FF

H'0080 H'0081 H'0082

H'03FF

H'0380 H'0381 H'0382

H'047F

H'0400 H'0401 H'0402

H'04FF

H'0480 H'0481 H'0482

H'07FF

H'0780 H'0781 H'0782

H'087F

H'0800 H'0801 H'0802

H'08FF

H'0880 H'0881 H'0882

H'0BFF

H'0B80 H'0B81 H'0B82

H'0C7F

H'0C00 H'0C01 H'0C02

H'0CFF

H'0C80 H'0C81 H'0C82

H'0FFF

H'0F80 H'0F81 H'0F82

H'107F

H'1000 H'1001 H'1002

H'10FF

H'1080 H'1081 H'1082

H'3FFF

H'3F80 H'3F81 H'3F82

Programming unit: 128 bytes

1 Kbyte

Erase unit

1 Kbyte

Erase unit

1 Kbyte

Erase unit

1 Kbyte

Erase unit

12 Kbytes

Erase unit

Figure 6.8(2) Block Configuration of 16-Kbyte Flash Memory
