Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 255 of 652
REJ09B0042-0700
Register Configuration
Table 9.5 shows the register configuration of timer C.
Table 9.5 Timer C Registers
Name Abbr. R/W Initial Value Address
Timer mode register C TMC R/W H'18 H'FFB4
Timer counter C TCC R H'00 H'FFB5
Timer load register C TLC W H'00 H'FFB5
Clock stop register 1 CKSTPR1 R/W H'FF H'FFFA
9.3.2 Register Descriptions
Timer Mode Register C (TMC)
Bit
Initial value
Read/Write
7
TMC7
0
R/W
6
TMC6
0
R/W
5
TMC5
0
R/W
4

1

3

1

0
TMC0
0
R/W
2
TMC2
0
R/W
1
TMC1
0
R/W
TMC is an 8-bit read/write register for selecting the auto-reload function and input clock, and
performing up/down-counter control.
Upon reset, TMC is initialized to H'18.
Bit 7—Auto-Reload Function Select (TMC7)
Bit 7 selects whether timer C is used as an interval timer or auto-reload timer.
Bit 7
TMC7 Description
0 Interval timer function selected (initial value)
1 Auto-reload function selected
