Bits 6 and 5—Counter Up/Down Control (TMC6, TMC5)
Selects whether TCC up/down control is performed by hardware using UD pin input, or whether
TCC functions as an up-counter or a down-counter.
Bit 6
TMC6
Bit 5
TMC5 Description
0 0 TCC is an up-counter (initial value)
0 1 TCC is a down-counter
1 * Hardware control by UD pin input
UD pin input high: Down-counter
UD pin input low: Up-counter
*: Don't care
Bits 4 and 3—Reserved
Bits 4 and 3 are reserved; they are always read as 1 and cannot be modified.
Bits 2 to 0—Clock Select (TMC2 to TMC0)
Bits 2 to 0 select the clock input to TCC. For external event counting, either the rising or falling
edge can be selected.
Bit 2
TMC2
Bit 1
TMC1
Bit 0
TMC0 Description
0 0 0 Internal clock: φ/8192 (initial value)
0 0 1 Internal clock: φ/2048
0 1 0 Internal clock: φ/512
0 1 1 Internal clock: φ/64
1 0 0 Internal clock: φ/16
1 0 1 Internal clock: φ/4
1 1 0 Internal clock: φ
W
/4
1 1 1 External event (TMIC): rising or falling edge
*
Note: * The edge of the external event signal is selected by bit IEG1 in the IRQ edge select
register (IEGR). See IRQ Edge Select Register (IEGR) in section 3.3.2 for details. IRQ1
in port mode register B (PMRB) must be set to 1 before setting 111 in bits TMC2 to TMC0.
