Section 2 CPU
Rev. 7.00 Mar 10, 2005 page 73 of 652
REJ09B0042-0700
Table 2.12 Registers with Shared Addresses
Register Name Abbreviation Address
Timer counter C/Timer load register C TCC/TLC H'FFB5
Port data register 1
*
PDR1 H'FFD4
Port data register 3
*
PDR3 H'FFD6
Port data register 4
*
PDR4 H'FFD7
Port data register 5
*
PDR5 H'FFD8
Port data register 6
*
PDR6 H'FFD9
Port data register 7
*
PDR7 H'FFDA
Port data register 8
*
PDR8 H'FFDB
Port data register A
*
PDRA H'FFDD
Note: * Port data registers have the same addresses as input pins.
Table 2.13 Registers with Write-Only Bits
Register Name Abbreviation Address
Port control register 1 PCR1 H'FFE4
Port control register 3 PCR3 H'FFE6
Port control register 4 PCR4 H'FFE7
Port control register 5 PCR5 H'FFE8
Port control register 6 PCR6 H'FFE9
Port control register 7 PCR7 H'FFEA
Port control register 8 PCR8 H'FFEB
Port control register A PCRA H'FFED
Timer control register F TCRF H'FFB6
PWM1 control register PWCR1 H'FFD0
PWM1 data register U PWDRU1 H'FFD1
PWM1 data register L PWDRL1 H'FFD2
PWM2 control register PWCR2 H'FFCD
PWM2 data register U PWDRU2 H'FFCE
PWM2 data register L PWDRL2 H'FFCF
Event counter PWM data register H ECPWDRH H'FF8E
Event counter PWM data register L ECPWDRL H'FF8F
