Renesas H8 Series Hardware Manual

Section 3 Exception Handling
Rev. 7.00 Mar 10, 2005 page 96 of 652
REJ09B0042-0700
Vector fetch
φ Internal address bus Internal read signal Internal write signal
(2)
Internal data bus (16 bits) Interrupt request signal
(9)
(1)
Internal processing
Prefetch instruction of interrupt-handling routine
(1) Instruction prefetch address (Instruction is not executed. Address is saved as PC contents, becoming return address.) (2)(4) Instruction code (not executed) (3) Instruction prefetch address (Instruction is not executed.) (5) SP − 2 (6) SP − 4 (7) CCR (8) Vector address (9) Starting address of interrupt-handling routine (contents of vector) (10) First instruction of interrupt-handling routine
(3) (9)(8)(6)(5)
(4) (1) (7) (10)
Stack access
Internal processing
Instruction prefetch
Interrupt level decision and wait for end of instruction
Interrupt is accepted
Figure 3.5 Interrupt Sequence
