Renesas H8 Series Hardware Manual

Section 3 Exception Handling
Rev. 7.00 Mar 10, 2005 page 100 of 652
REJ09B0042-0700
Interrupt Request
Flags Set to 1 Conditions
IWPR IWPF7
When PMR5 bit WKP7 is changed from 0 to 1 while pin
WKP
7
is low and WEGR bit
WKEGS7 = 0.
When PMR5 bit WKP7 is changed from 1 to 0 while pin
WKP
7
is low and WEGR bit
WKEGS7 = 1.
IWPF6
When PMR5 bit WKP6 is changed from 0 to 1 while pin
WKP
6
is low and WEGR bit
WKEGS6 = 0.
When PMR5 bit WKP6 is changed from 1 to 0 while pin
WKP
6
is low and WEGR bit
WKEGS6 = 1.
IWPF5
When PMR5 bit WKP5 is changed from 0 to 1 while pin
WKP
5
is low and WEGR bit
WKEGS5 = 0.
When PMR5 bit WKP5 is changed from 1 to 0 while pin
WKP
5
is low and WEGR bit
WKEGS5 = 1.
IWPF4
When PMR5 bit WKP4 is changed from 0 to 1 while pin
WKP
4
is low and WEGR bit
WKEGS4 = 0.
When PMR5 bit WKP4 is changed from 1 to 0 while pin
WKP
4
is low and WEGR bit
WKEGS4 = 1.
IWPF3
When PMR5 bit WKP3 is changed from 0 to 1 while pin
WKP
3
is low and WEGR bit
WKEGS3 = 0.
When PMR5 bit WKP3 is changed from 1 to 0 while pin
WKP
3
is low and WEGR bit
WKEGS3 = 1.
IWPF2
When PMR5 bit WKP2 is changed from 0 to 1 while pin
WKP
2
is low and WEGR bit
WKEGS2 = 0.
When PMR5 bit WKP2 is changed from 1 to 0 while pin
WKP
2
is low and WEGR bit
WKEGS2 = 1.
IWPF1
When PMR5 bit WKP1 is changed from 0 to 1 while pin
WKP
1
is low and WEGR bit
WKEGS1 = 0.
When PMR5 bit WKP1 is changed from 1 to 0 while pin
WKP
1
is low and WEGR bit
WKEGS1 = 1.
IWPF0
When PMR5 bit WKP0 is changed from 0 to 1 while pin
WKP
0
is low and WEGR bit
WKEGS0 = 0.
When PMR5 bit WKP0 is changed from 1 to 0 while pin
WKP
0
is low and WEGR bit
WKEGS0 = 1.
Figure 3.7 shows the procedure for setting a bit in a port mode register and clearing the interrupt
request flag.
When switching a pin function, mask the interrupt before setting the bit in the port mode register
(or AEGSR). After accessing the port mode register (or AEGSR), execute at least one instruction
(e.g., NOP), then clear the interrupt request flag from 1 to 0. If the instruction to clear the flag is
