Section 5 Power-Down Modes

Rev. 7.00 Mar 10, 2005 page 142 of 652

REJ09B0042-0700

CKSTPR2 LDCKSTP 1 LCD module standby mode is cleared

0 LCD is set to module standby mode

PW1CKSTP 1 PWM1 module standby mode is cleared

0 PWM1 is set to module standby mode

WDCKSTP 1 Watchdog timer module standby mode is cleared

0 Watchdog timer is set to module standby mode

AECKSTP 1 Asynchronous event counter module standby mode

is cleared

0 Asynchronous event counter is set to module standby

mode

PW2CKSTP 1 PWM2 module standby mode is cleared

0 PWM2 is set to module standby mode

LVDCKSTP* 1 LVD module standby mode is cleared

0 LVD is set to module standby mode

Notes: For details of module operation, see the sections on the individual modules.

* LVDCKSTP is implemented on the H8/38124 group only.
