Section 6 ROM

Rev. 7.00 Mar 10, 2005 page 148 of 652

REJ09B0042-0700

Start

Set write/verify mode

V = 6.0 V ± 0.25 V, V = 12.5 V ± 0.3 V

CC PP

Address = 0

n = 0

n + 1 n

→

Verify

Write time t = 0.2n ms

OPW

Last address?

Set read mode

V = 5.0 V ± 0.25 V, V = V

CC PP CC

Read all

addresses?

End

Error

n < 25

Address + 1 address→

Yes

Write time t = 0.2 ms ± 5%

Figure 6.4 High-Speed, High-Reliability Programming Flowchart
