Section 6 ROM
Rev. 7.00 Mar 10, 2005 page 166 of 652
REJ09B0042-0700
Table 6.8 Boot Mode Operation
Item
Host Operation LSI Operation
Branches to boot program at reset-start.
Processing Contents Processing Contents
Bit rate
adjustment
Flash memory erase
Continuously transmits data H'00 at
specified bit rate.
· Measures low-level period of receive data H'00.
· Calculates bit rate and sets it in BRR of SCI3.
· Transmits data H'00 to the host to indicate that the
adjustment has ended.
Checks flash memory data, erases all flash memory
blocks in case of written data existing, and transmits
data H'AA to host. (If erase could not be done,
transmits data H'FF to host and aborts operation.)
Transmits data H'55 when data H'00
is received and no error occurs.
Transmits number of bytes (N) of
programming control program to be
transferred as 2-byte data (low-order
byte following high-order byte)
Transmits 1-byte of programming
control program
Transfer of
programming control
program
Execution of
Programming
control program
Transfer of
programming control
program (repeated for
N times)
Echobacks the 2-byte received data to host.
Transmits 1-byte data H'AA to host.
Branches to programming control program
transferred to on-chip RAM and starts execution.
Echobacks received data to host and also
transfers it to RAM.
Table 6.9 Oscillating Frequencies (f
OSC
) for which Automatic Adjustment of LSI Bit Rate
Is Possible
Product Group Host Bit Rate Oscillating Frequencies (f
OSC
) Range of LSI
4,800 bps 8 to 10 MHz
2,400 bps 4 to 10 MHz
F-ZTAT version of
H8/38024 Group and
F-ZTAT version of
H8/38024R Group
1,200 bps 2 to 10 MHz
19,200 bps 16 to 20 MHzF-ZTAT version of
H8/38124 Group
9,600 bps 8 to 20 MHz
4,800 bps 6 to 20 MHz
2,400 bps 2 to 20 MHz
1,200 bps 2 to 20 MHz
