16.8.1 Power Supply
Voltage and Operating
Ranges
Power Supply Voltage
and Oscillation
Frequency Range
(System Clock
Oscillator Selected)
506 Figure amended
2.0
20.0
2.7 5.5
V
CC (V)
fosc (MHz)
• Active (high-speed) mode
• Sleep (high-speed) mode
Power Supply Voltage
and Operating
Frequency Range
(System Clock
Oscillator Selected)
507 Figure amended
10.0
1.0
2.7 5.5
V
CC (V)
φ (MHz)
• Active (high-speed) mode
• Sleep (high-speed) mode (except CPU)
1250
15.625
2.7 5.5
V
CC (V)
φ (kHz)
• Active (medium-speed) mode
• Sleep (medium-speed) mode (except A/D converter)
