Page #256 background imageLoading...
Page #256 background image
Section 8 I/O Ports
Rev. 7.00 Mar 10, 2005 page 214 of 652
REJ09B0042-0700
Port Data Register 5 (PDR5)
Bit 76543210
P5
7
P5
6
P5
5
P5
4
P5
3
P5
2
P5
1
P5
0
Initial value 0 0 0 0 0 0 0 0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
PDR5 is an 8-bit register that stores data for port 5 pins P5
7
to P5
0
. If port 5 is read while PCR5
bits are set to 1, the values stored in PDR5 are read, regardless of the actual pin states. If port 5 is
read while PCR5 bits are cleared to 0, the pin states are read.
Upon reset, PDR5 is initialized to H'00.
Port Control Register 5 (PCR5)
Bit
Initial value
Read/Write
7
PCR5
0
W
6
PCR5
0
W
5
PCR5
0
W
4
PCR5
0
W
3
PCR5
0
W
0
PCR5
0
W
2
PCR5
0
W
1
PCR5
0
W
76543210
PCR5 is an 8-bit register for controlling whether each of the port 5 pins P5
7
to P5
0
functions as an
input pin or output pin. Setting a PCR5 bit to 1 makes the corresponding pin an output pin, while
clearing the bit to 0 makes the pin an input pin. PCR5 and PDR5 settings are valid when the
corresponding pins are designated for general-purpose input/output by PMR5 and bits SGS3 to
SGS0 in LPCR.
Upon reset, PCR5 is initialized to H'00.
PCR5 is a write-only register, which is always read as all 1s.
